Adaptive Per-Function CPU Time Tracking
Context
Velox evaluates SQL expressions as trees of functions. A query like
if(array_gte(a, b), multiply(x, y), 0) compiles into a tree where each node
processes an entire vector of rows at a time. When a query runs slowly, the
first question usually is: which function is consuming the most CPU? Is it the
expensive array comparison, or the cheap arithmetic called millions of times?
This problem is even more prominent in use cases like training data loading,
when very long and deeply nested expression trees are common, and jobs may run
for many hours, or days; in such cases, the CPU usage of even seemingly
short-lived functions may add up to substantial overhead. Without a detailed
per-function CPU usage breakdown, you may be left guessing — or worse,
optimizing the wrong thing.
Velox supports CPU usage tracking through the expression.track_cpu_usage query
config. When enabled, every function invocation is wrapped in a CpuWallTimer
— an RAII guard that makes the clock_gettime() system call at entry and exit,
recording the CPU and wall time spent in each function. This gives precise,
per-function cost attribution across the entire expression tree.
The Overhead Problem
That precision comes at a price. Each CpuWallTimer invocation performs a heap
allocation, two clock_gettime() syscalls, and a heap deallocation — roughly
~5μs of fixed overhead, depending on the platform. For a function like
array_gte(), which spends milliseconds per vector iterating over array
elements, 5μs is a negligible noise. But for a function like multiply that
incurs a single instruction, the timer takes longer than the work itself:
| Vector Size | No Tracking | Full Tracking | Overhead |
|---|---|---|---|
| 100 rows | 2.13ms | 5.89ms | 2.8x |
| 1,000 rows | 300μs | 668μs | 2.2x |
| 10,000 rows | 193μs | 233μs | 1.2x |
Benchmark for multiply(a, b) on double columns. Times are per 10K
iterations.
This overhead forced production systems to disable per-function CPU tracking
entirely, losing visibility into more granular CPU consumption. Selective
per-function tracking (expression.track_cpu_usage_for_functions) was added to
Velox in the past to let operators opt in specific functions, but even for
tracked functions the overhead remained — you just chose which functions to pay
the cost for.
Why Uniform Sampling Falls Short
The obvious next step is to sample: measure every Nth vector instead of every one, and extrapolate. A uniform rate applied to all functions would be simple — one counter, one config key. But a single rate cannot serve both cheap and expensive functions.
Consider array_gte, where the timer overhead is less than 0.1% of execution
time. Sampling in this case throws away measurement precision for no benefit —
the function can afford full tracking. Now consider multiply on small vectors,
where the timer is 2500% of the function cost. Even a 1/1000 rate may not be
aggressive enough. A rate that works for one function is either inaccurate or
insufficient for another.
Adaptive Per-Function Sampling
When a query starts running, adaptive sampling does not yet know which functions are cheap and which are expensive. So it watches.
The first vector through each function is a warmup — caches and branch
predictors settle, and the system measures the cost of the CpuWallTimer itself
by creating and destroying a dummy one. Over the next 5 vectors, each function
runs with a lightweight stopwatch instead, quietly accumulating how long it
actually takes without any timer overhead.
By the sixth vector, the system has what it needs: the ratio of timer overhead
to function cost. If the ratio is within a configurable threshold (default 1%),
the function switches to full tracking: every future vector gets a
CpuWallTimer, with zero information loss. If the timer dominates, the function
switches to sampling at a rate that bounds overhead to the threshold:
| Function | Per-Vector Cost | Timer Overhead | Overhead Ratio | Decision |
|---|---|---|---|---|
multiply(a,b) 100 rows | ~0.2μs | ~5μs | 2500% | Sample 1/2500 |
multiply(a,b) 10K rows | ~20μs | ~5μs | 25% | Sample 1/25 |
array_gte(a,b) 100 rows | ~3ms | ~5μs | 0.17% | Always track |
array_gte(a,b) 10K rows | ~12ms | ~5μs | 0.04% | Always track |
Expensive functions get exact tracking. Cheap functions sample aggressively. No per-function configuration needed — just a single "max acceptable overhead" knob.
When stats are read, sampled functions have their CPU and wall time scaled up by the ratio of total vectors to timed vectors. To handle short queries where the sampling counter might never fire, the first post-calibration vector is always timed, guaranteeing at least one measurement to extrapolate from.
Results
So does it work? We benchmarked adaptive sampling against both no tracking and full tracking, across cheap and expensive functions, at different vector sizes, and with different adaptive rates (1% and 0.5%). Results are presented below:
| Benchmark | No Tracking | Full Tracking | Adaptive 1% | Adaptive 0.5% |
|---|---|---|---|---|
| multiply 100 rows | 2.13ms | 5.86ms (36%) | 2.19ms (97%) | 2.16ms (98%) |
| multiply 1K rows | 299μs | 671μs (44%) | 304μs (98%) | 302μs (99%) |
| multiply 10K rows | 193μs | 224μs (86%) | 165μs (117%) | 193μs (100%) |
| array_gte 100 rows | 188ms | 193ms (98%) | 189ms (100%) | 187ms (100%) |
| array_gte 1K rows | 32ms | 32ms (100%) | 32ms (100%) | 32ms (100%) |
| array_gte 10K rows | 11ms | 11ms (100%) | 11ms (100%) | 11ms (100%) |
(Percentages are relative to "No Tracking" — higher is better)
For multiply on 100-row vectors, overhead drops from 64% to under 3%. For
array_gte, overhead was already negligible and remains so — the function is
fully tracked with near zero sampling.
The natural concern with sampling is accuracy. We ran a correctness benchmark comparing the extrapolated CPU time from adaptive sampling against the true value from full tracking over 1,000 vectors:
| Function | 100 rows | 1,000 rows | 10,000 rows |
|---|---|---|---|
| multiply | 108.8% | 102.4% | 103.7% |
| array_gte | 99.8% | 100.3% | 99.6% |
Estimates land within 1–9% of the true value. For expensive functions that end up in always track mode, accuracy is exact — every vector is timed.
Configuration
Two config properties control adaptive sampling:
| Config | Type | Default | Description |
|---|---|---|---|
expression.adaptive_cpu_sampling | bool | false | Enable adaptive per-function sampling |
expression.adaptive_cpu_sampling_max_overhead_pct | double | 1.0 | Target max overhead percentage |
Adaptive sampling interacts cleanly with existing tracking modes.
expression.track_cpu_usage (global tracking for all functions) takes highest
priority and always wins. expression.track_cpu_usage_for_functions (selective
per-function tracking) overrides adaptive for named functions. Adaptive sampling
applies to everything else.
Takeaway
Adaptive per-function CPU time tracking eliminates the tradeoff between observability and performance. Every function gets the best tracking mode for its cost profile — cheap functions run at near-native speed with minimal overhead, expensive functions get exact tracking at zero additional cost. The system is self-tuning and requires no per-function configuration.
